FLEXIBLE LED MODULES

Flexible LED DISPLAY MODULE

Overview

  • Ultra-high flexibility, suitable for LED displays of any shape.
  • Most suitable for indoor, 160-degree visibility.
  • RGB full-color LED screen panel
  • Equipped with built-in strong magnetic screws for improved front maintenance operations.
  • Low brightness of more than 600-1000 Nits for indoor mounting.
  • Highly stable driver ICs for improved color uniformity and rich images.
  • 5000:1 high contrast ratio to produce rich colors.
  • Higher refresh rate of more than 1920hz to 3840Hz to enable flicker-free.
  • Pixel pitch varies from P1.2, P1.5, P1.8, P2, P2.5, P3, etc.
  • Made with high-grade materials such as PCB boards, driver ICs, LEDs, resistors, capacitors, and magnetic screws.

Types Of lED Module product

Flexible LED display by trusted LED screen supplier in Dubai
flexible-indoor-led-display-module
flexible-led-display-module
flexible-led-module-display

P 1.2 Flexible Indoor LED Module

  • 1.2mm pitch for superior image clarity and high-definition performance.
  • 3,200 dots with an 80×40 grid matrix for detailed visuals.
  • Ultra-flexible construction ideal for curved or creative indoor LED displays.
  • Dimensions: 240mm × 120mm (9.44” × 4.72”).
  • 160-degree horizontal and vertical visibility for maximum audience reach.
  • SMD 1R1G1B full-color encapsulation for rich, vibrant output.
  • Adjustable from 600 to 1,000 nits for indoor environments.
  • 1/13 constant current scan for stable performance.
  • Over 3840Hz to ensure smooth, flicker-free visuals.
  • Equipped with highly stable driver ICs for consistent image quality.
Contact us
Flexible LED display by trusted LED screen supplier in Dubai
flexible-indoor-led-display-module
flexible-led-display-module
flexible-led-module-display

P 1.5 Flexible Indoor LED Module

  • Resolution: High-density display with 80×40 grid matrix for sharp and smooth visuals.
  • 1.5mm pixel pitch for excellent close-range viewing and high image clarity.
  • Ultra-flexible design, ideal for curved, wave, or creative LED display structures.
  • Dimensions: 240mm × 120mm / 9.44” × 4.72”.
  • Wide 160-degree viewing angle for maximum indoor visibility.
  • SMD 1R1G1B full-color LED panel for superior color accuracy and brightness.
  • Constant current 1/13 scan for stable image output and consistent performance.
  • Brightness range: 600–1000 nits, optimized for indoor environments.
  • Equipped with high-stability driver ICs for improved color uniformity.
  • High contrast ratio of 5000:1 for deep blacks and vibrant visuals.
  • Refresh rate over 3840Hz, ensuring smooth and flicker-free display.
Contact us
SpecificationDetails
Pixel Pitch1.5mm
LED TypeSMD
Module Resolution160x80 pixels
Module Size240mm x 120mm
Module Weight0.35kg
Brightness≥800 nits
Refresh Rate≥3840Hz
Gray Scale16-bit
Viewing Angle160°(H)/160°(V)
Contrast Ratio5000:1
Power Consumption (Max)≤ 600W/m²
Power Consumption (Avg)≤ 200W/m²
Working VoltageAC 100-240V, 50/60Hz
Bend Radius≥100mm
Operating Temperature-10°C to 45°C
Humidity Range10% - 90% RH
Protection LevelIP40
Lifetime≥100,000 hours
Driving MethodConstant Current
Flexibility FeatureSoft, Curvable Design
Flexible LED display by trusted LED screen supplier in Dubai
flexible-indoor-led-display-module
flexible-led-display-module
flexible-led-module-display

P 1.8 Flexible Indoor LED Module

  • Resolution: 3,200 dots with 80×40 grid matrix for detailed and sharp image output.
  • 1.8mm pixel pitch for high-resolution performance with clear visual quality.
  • Flexible design, ideal for creative LED displays including curves, cylinders, and waves.
  • Dimensions: 240mm × 120mm / 9.44” × 4.72”.
  • Wide 160-degree viewing angle for optimal indoor audience coverage.
  • SMD 1R1G1B full-color LED screen panel for vibrant, full-color image presentation.
  • Constant current 1/13 scan for stable and consistent performance.
  • Brightness range: 600–1,000 nits, perfect for various indoor lighting conditions.
  • High-stability driver ICs ensure uniform color and reduced power consumption.
  • High contrast ratio of 5000:1 to deliver rich, vivid colors and deeper blacks.
  • Refresh rate above 3840Hz for flicker-free visuals, ideal for video content.
Contact us
SpecificationDetails
Pixel Pitch1.8mm
LED TypeSMD
Module Resolution133x67 pixels
Module Size240mm x 120mm
Module Weight0.38kg
Brightness≥800 nits
Refresh Rate≥3840Hz
Gray Scale16-bit
Viewing Angle160°(H)/160°(V)
Contrast Ratio5000:1
Power Consumption (Max)≤ 580W/m²
Power Consumption (Avg)≤ 190W/m²
Working VoltageAC 100-240V, 50/60Hz
Bend Radius≥110mm
Operating Temperature-10°C to 45°C
Humidity Range10% - 90% RH
Protection LevelIP40
Lifetime≥100,000 hours
Driving MethodConstant Current
Flexibility FeatureSoft, Curvable Design
Flexible LED display by trusted LED screen supplier in Dubai
flexible-indoor-led-display-module
flexible-led-display-module
flexible-led-module-display

P 2.5 Flexible Indoor LED Module

  • Resolution: 4,608 dots with 96×48 grid matrix; 8,192 dots with 128×64 grid matrix.
  • 2.5mm pixel pitch for better visual performance with good Clarity.
  • Ultra-high flexibility, the idea for a creative LED display.
  • Dimensions: 320mm x 160mm / 12.5” x 6.2”; 240mm x 120mm / 9.44” x 4.72”.
  • Best for indoor, 160-degree visibility.
  • 1R1G1B full-color LED screen panel.
  • Constant current 1/24, 1/32 scan.
  • 600 -1,000 nits brightness.
  • Highly stable driver ICs for better color uniformity and vibrant images
  • Designed with the latest SMD 1R1G1B encapsulation, offering excellent full color presentation.
Contact us
Flexible LED display by trusted LED screen supplier in Dubai
flexible-indoor-led-display-module
flexible-led-display-module
flexible-led-module-display

P 3 Flexible Indoor LED Module

  • Resolution: 3,200 dots with 80×40 grid matrix
  • 3mm pixel pitch for better visual performance with good Clarity.
  • Ultra-high flexibility, idea for creative LED display
  • Dimensions: 240mm x 120mm / 9.44” x 4.72”.
  • Best for indoor, 160-degree visibility.
  • 1R1G1B full-color LED screen panel.
  • Constant current 1/13 scan.
  • 600-1,000 nits brightness.
  • Highly stable driver ICs for better color uniformity and vibrant images
  • Designed with the latest SMD 1R1G1B encapsulation, offering excellent full color present.
  • High contrast ratio of 5000:1 to deliver vibrant colors.
  • High refresh rate with over 3840Hz to allow flicker-free
Contact us
ItemSpecification
Pixel Pitch3 mm
LED TypeSMD2121
Module Resolution64 x 64 pixels
Module Size192 mm x 192 mm
Pixel Density111111 pixels/m²
Brightness≥ 1000 cd/m²
Refresh Rate≥ 1920 Hz
Gray Scale14-16 bit
Viewing AngleHorizontal 140°, Vertical 140°
Driving Method1/32 Scan
Module Weight0.2 kg
Input VoltageDC 5V
Power ConsumptionMax 20W
Working Temperature-20°C to +60°C
Humidity10% ~ 90% RH
Lifespan≥ 100,000 hours
InstallationMagnetic or Frame Fixed
ApplicationIndoor – Curved, Cylindrical, Wavy Surfaces

characteristic

Pixel Pitch

5500 Nits and above, 7000 Nits even, outdoor use under strong sunlight

Ultra Flexible

Designed to maximize flexibility and bendability, offering you the ability to design any kind of creative LED display with a variety of patterns or shapes in an easy way.

High Resolution

High-protection PCB board, IP65 usage level, long time outdoor use

Strong Magnets

With high-performance magnets to help the flexible LED modules can adhere to metal surfaces in a very tight fit, while you never have to worry about them falling off.

Wide Viewing

160 viewing angles, minimal blind spot, maximum visual coverage, great visual experience

Front Service Installation

The flexible module is designed for frontal maintenance. The LED modules can be easily & quickly taken out and disassembled from the iron frame surface in seconds with a few steps
